Wherwell Priory Estate is a large scale estate irrigation project comprising two separate borehole fed irrigation systems.
Project Details
Wherwell Priory Estate is a large scale estate irrigation project comprising two separate borehole fed systems. The first completed system was designed to support extensive lawns and planted areas across the estate, using a private borehole supply and large underground water storage.
#1 Type
System type
Large scale estate irrigation system.
#2 Source
Water source
Borehole fed with underground storage.
#3 Brands
Key brands
Grundfos, Hunter Hydrawise, Enduramaxx, Rain Bird, Palaplast.
#4 Suitability
Best for
Estate scale irrigation, large lawns and extensive planted areas.
The installation includes a 10,000 litre underground Enduramaxx water storage tank and two Grundfos SQE borehole pumps with constant pressure control. This gives the system the water supply and pressure stability required for an estate scale irrigation installation.
The system is managed by a Hunter HCC Hydrawise controller and uses a two wire decoder system for efficient control across the site. Rain Bird 5000 Series rotors and Rain Bird 1800 Series pop up sprinklers with R VAN rotary nozzles provide lawn coverage, while Palaplast Paladrip pressure compensated dripline is used for planted areas. HDPE mainline pipework forms the main irrigation distribution network.
Key system features
This project shows Hortlands’ ability to deliver large scale automatic irrigation systems for estates, combining borehole water supply, underground storage, constant pressure pumping, smart control and professional sprinkler and dripline specification.
Large scale estate irrigation system
Borehole fed water supply
10,000 litre underground Enduramaxx water storage tank
Two Grundfos SQE borehole pumps
Constant pressure control system
Hunter HCC Hydrawise smart irrigation controller
Two wire decoder system
Rain Bird 5000 Series rotors
Rain Bird 1800 Series pop up sprinklers
R VAN rotary nozzles
HDPE mainline pipework
Palaplast Paladrip pressure compensated dripline
