Big Frith uses a comprehensive borehole fed irrigation system designed for reliable automatic watering across lawns and planting areas.
Project Details
Big Frith required a comprehensive irrigation system capable of supporting a large garden with lawns, planted areas and varied watering requirements. The system was designed around a borehole supply, giving the garden access to a private water source rather than relying solely on mains water.
#1 Type
System type
Borehole fed automatic irrigation system
#2 Source
Water source
Borehole with 10,000 litre underground tank
#3 Brands
Key brands
Grundfos, Hunter Hydrawise, Enduramaxx, Rain Bird, Palaplast
#4 Suitability
Best for
Large gardens requiring reliable irrigation from a private water source
The installation includes a Grundfos SQE submersible borehole pump with constant pressure control, allowing the system to maintain consistent performance during operation. Water is stored in a 10,000 litre underground Enduramaxx tank before being distributed through the irrigation network.
The system is controlled by a Hunter HCC Hydrawise controller and uses a two wire decoder system for efficient control across the site. Rain Bird 5000 Series rotors and Rain Bird 1800 Series pop up sprinklers with R VAN rotary nozzles provide lawn irrigation, while Palaplast Paladrip pressure compensated dripline delivers water directly to the planting areas.
Request a site survey
Key system features
This upgrade created a more practical and dependable irrigation system for the completed landscaping scheme, helping the garden establish properly and making day to day watering easier to manage.
Above ground 5,000 litre water storage tank
DAB Divertek 900 submersible pump
Hunter HCC Hydrawise smart irrigation controller
Two wire decoder system
Rain Bird 5000 Series rotors
Rain Bird 1800 Series pop up sprinklers
R VAN rotary nozzles
HDPE irrigation pipework
Palaplast Paladrip pressure compensated dripline
Every project starts with a free, no-obligation site visit and quote.
