Elmhurst required a fully automatic irrigation system with significant water storage capacity.
Project Details
Elmhurst required a fully automatic irrigation system with a larger water storage capacity to support the garden’s watering requirements. The system is supplied from two linked 5,000 litre above ground water storage tanks, giving the installation a total stored water capacity suitable for a larger landscaped garden.
#1 Type
System type
Large tank fed automatic irrigation system
#2 Source
Water source
Two linked 5,000 litre above ground tanks
#3 Brands
Key brands
Lowara, Hydrovar, Hunter Hydrawise, Rain Bird, Palaplast
#4 Suitability
Best for
Larger gardens needing controlled irrigation across multiple areas
Water is delivered through the system by a Lowara surface mounted pump with Hydrovar variable speed control. The irrigation is managed by a Hunter HCC Hydrawise controller, allowing the watering schedule to be controlled and adjusted through a smart irrigation platform.
A two wire decoder system was installed to support control across the garden. Rain Bird 5000 Series rotors and Rain Bird 1800 Series pop up sprinklers with R VAN rotary nozzles provide lawn irrigation, while Palaplast Paladrip pressure compensated dripline waters the planting areas. HDPE mainline pipework forms the core distribution network.
Request a site survey
Key system features
This project provides a strong example of a larger automatic irrigation system using stored water, smart control and professional grade sprinkler and dripline components.
Two linked 5,000 litre above ground water storage tanks
Lowara surface mounted pump
Hydrovar variable speed control
Hunter HCC Hydrawise smart irrigation controller
Two wire decoder system
Rain Bird 5000 Series rotors
Rain Bird 1800 Series pop up sprinklers
R VAN rotary nozzles
HDPE mainline pipework
Palaplast Paladrip pressure compensated dripline
